Hand Dumbwaiters
Page 1
Return to elevatorbob's Elevator Pictures
Image 1
Yonah Schimmel Knish Bakery 137 East Houston Street New York City, New York, U.S.A. (1 of 2)
Image provided by: Herbie T. Mann
I know more!
Image 2
All loaded up and ready to travel...are you hungry yet?! (2 of 2)
Image provided by: Herbie T. Mann
I know more!
Image 3
A monastery in Greece
Image provided by: Adolf Fritz
I know more!
Image 4
The remnants of a hand dumbwaiter at Guys Cliffe House in Warwickshire, United Kingdom (1 of 2)
Image provided by: Will Gregory
I know more!
Image 5
Another view of the hand dumbwaiter at Guys Cliffe House in Warwickshire, United Kingdom (2 of 2)
View the larger image - it appears that the "drive" sheave just barely fits...
Image provided by: Will Gregory
I know more!
Image 6
This looks pretty safe...doesn't it?!
Image provided by: Herbie T. Mann
I know more!
Image 7
...and so does this!
Image provided by: Kobe Nartuiani
I know more!
Image 8
If you have a tree house...you need one of these! (1 of 2)
See the tree on the left and the dumbwaiter next to the bookshelf...
Image provided by: Igor Trinsky
I know more!
Image 9
Another view...
...apparently the floor swings down to open up the hoistway for passage of the "dumbwaiter". (2 of 2)
Image provided by: Igor Trinsky
I know more!
Image 10
Or perhaps the economy tree house "dumbwaiter" is more to your liking... (1 of 2)
dual buckets (only one bucket shown - for simplicity)
Image provided by: Wilson Smith
I know more!
Image 11
A close-up of the car...their leakproof model! (2 of 2)
Image provided by: Wilson Smith
I know more!
Image 12
I'm not sure if this is a dumbwaiter but I like the picture so...it's a dumbwaiter
Image provided by: Sharon Midays
I know more!
Image 13
A beautiful hand dumbwaiter installed at the
Winchester Mystery House in San Jose, California, U.S.A. (1 of 5)
Is that a "special" dumbwaiter knot in that rope?
Image provided by: Herbie T. Mann
I know more!
Image 14
A slightly different view... (2 of 5)
Image provided by: Herbie T. Mann
I know more!
Image 15
There are, of course, two ropes involved in that knot...
the counterweight rope and the hand-rope (3 of 5)
Image provided by: Herbie T. Mann
I know more!
Image 16
A close-up of the overhead sheaves... (4 of 5)
Image provided by: Herbie T. Mann
I know more!
Image 17
Herbie says these are landing doors for another dumbwaiter in the same home... (5 of 5)
Image provided by: Herbie T. Mann
I know more!
Image 18
You just know this was put together in someone's garage (1 of 6)
At the top landing...
Image provided by: Justin Morris
I know more!
Image 19
...at the bottom landing (2 of 6)
Image provided by: Justin Morris
I know more!
Image 20
There is a "guard" at the top landing... (3 of 6)
Image provided by: Justin Morris
I know more!
Image 21
The counterweight... (4 of 6)
Image provided by: Justin Morris
I know more!
Image 22
Looking up the hoistway... (5 of 6)
Image provided by: Justin Morris
I know more!
Image 23
Looking down on the car... (6 of 6)
Image provided by: Justin Morris
I know more!
Image 24
Somewhere in Brazil...
Image provided by: Cody Tangiers
I know more!
Image 25
Image provided by: Sandra Barry
I know more!
Image 26
Gears and a wooden guide...
Image provided by: Amos Lindsey
I know more!
Image 27
Looking up at the bottom of a hand dumbwaiter car...
Image provided by: Roland Low
I know more!
Image 28
Dumbwaiter in the admiral's quarters on the USS North Carolina...
Image provided by: Herbie T. Mann
I know more!
Image 29
Quite a door on this unit...
Image provided by: Shawn Woodhum
I know more!
Image 30
Devil in the dumbwaiter...
Image provided by: Ernie Pyle
I know more!
