Image 1
Flyball governor
Image provided by: Patrick MaGroen
Image 2
Otis flyball governor
Image provided by: Patrick MaGroen
Image 3
An example of an early type of disconnecting means
Image provided by: Patrick MaGroen
Image 4
Image provided by: Patrick MaGroen
Image 5
Controller for one of the Golden Gate Bridge geared elevators
Image provided by: Regent Isamoné
Image 6
Image provided by: Hans van Lunsen - Holland
Image 7
Controller for this machine
Image provided by: Hans van Lunsen - Holland
Image 8
Close-up of the UP & DOWN mercury relays on the controller for this machine
Image provided by: Hans van Lunsen - Holland
Image 9
An Otis controller
Image provided by: Patrick MaGroen
Image 10
Close-up of Otis relays
Image provided by: Patrick MaGroen
Image 11
An Otis Elevator controller on display at the London Transport Museum
Image provided by: Patrick MaGroen
Image 12
Otis selector leveling cams ("pie plates")
Image provided by: Ken Fowler
Image 13
Image provided by: Ken Fowler
Image 14
Where is the proper working clearance?
Image provided by: Ken Fowler
Image 15
Image provided by: Hans van Lunsen - Holland
Image 16
Image provided by: Hans van Lunsen - Holland
Image 17
A rope brake
Image provided by: Hans van Lunsen - Holland
Image 18
A United States Elevator Company controller
Image provided by: Chris Williams - U.S.A.
Image 19
An old selector (Do you know the manufacturer? E-mail me...please)
Image provided by: Chris Williams - U.S.A.
Image 20
Close-up of old selector (Do you know the manufacturer? E-mail me...please)
Image provided by: Chris Williams - U.S.A.
Image 21
Armor controller
Image provided by: Chris Williams - U.S.A.
Image 22
Close-up of Armor controller
Image provided by: Chris Williams - U.S.A.
Image 23
A rear view of an Otis controller
Image provided by: Chris Williams - U.S.A.
Image 24
Six Otis motor-generator sets and starter panels
Image provided by: Chris Williams - U.S.A.
Image 25
An Otis selector and gearless traction machine
Image provided by: Chris Williams - U.S.A.
Image 26
Close-up of the Otis selector
Image provided by: Chris Williams - U.S.A.
Image 27
A front view of an Otis controller
Image provided by: Will Rinkhum
Image 28
A front view of an Otis dispatching/group controller
Image provided by: Will Rinkhum
Image 29
A front view of an old Otis private residence elevator controller
Image provided by: Joe Harvey
Image 30
A front view of a very old Otis controller equipped with wooden knobs.
Are the wooden knobs used to manually manipulate the controller to move the car up or down?
(Do you know what the knobs are for? E-mail me...please)
Image provided by: Will Rinkhum
