Hoistway Landing Entrances
Freight Elevator Doors
Page 1
Return to elevatorbob's Hoistway Landing Entrances
Return to elevatorbob's Elevator Pictures
Image 1 (1 of 2)
A set of center opening wooden freight car landing doors...
Image provided by: Fred Small
I know more!
Image 2 (2 of 2)
A close-up of the wood and hinge detail...
Image provided by: Fred Small
I know more!
Image 3
A derelict freight elevator in Berlin, Germany
Image provided by: Olga Marks
I know more!
Image 4
The "In case of fire..." sign still looks pretty good at the derelict
Bethlehem Steel plant - Bethlehem, Pennsylvania, U.S.A.
Image provided by: Herbie T. Mann
I know more!
Image 5
Tagged and branded!
Image provided by: Pablo Torres
I know more!
Image 6
Another derelict freight elevator with center opening swing doors...
Image provided by: Pablo Torres
I know more!
Image 7
This is supposed to be a freight elevator landing door...
but I do not know what type or how it opens!
Image provided by: Ken Fowler does not know either...
I know more!
Image 8
What's behind those biparting doors?
Image provided by: Phillip McKraken
I know more!
Image 9
Interesting...
Image provided by: Carney Watts
I know more!
Image 10
A freight landing that you can back a truck up to...
Brooklyn, New York, U.S.A.
Image provided by: Möv Ingwalk
I know more!
Image 11
Would this be a set of center opening bifolding doors?
Image provided by: Paddy Noustor
I know more!
Image 12
A roller shutters type landing door...somewhere in the United Kingdom
Image provided by: Herbie T. Mann
I know more!
Image 13
There are two freight elevator biparting doors on the left side of the picture.
The first entrance seems to have the bottom half of the biparting door on the floor above
protruding by the lintel (head jamb). The code calls this a "pass-type entrance."
(See 2.11.12.4.7 ASME A17.1S-2005)
Image provided by: Reg Thourpe
I know more!
Image 14
You can't miss this freight door in New York, New York, U.S.A.
Image provided by: Neil Ott
I know more!
Image 15
Fire doors protect this freight elevator entrance...
Image provided by: Uri Nace
I know more!
Image 16
This looks like a garage door and opener...
The Stutz Building in Indianapolis, Indiana, U.S.A.
Image provided by: Dave Mare
I know more!
Image 17
I do not know where this is located but...
they are lucky enough to have two freight elevators.
Image provided by: Frederick Kaylor
I know more!
Image 18
Double swing doors in Brussels, Belgium
Image provided by: Lars Dorian
I know more!
Image 19
A nice shade of green...
Image provided by: Roger Feder
I know more!
Image 20
An outdoor entrance in Monroe, Louisiana, U.S.A.
Image provided by: Carl Cajun
I know more!
Image 21
Center-opening horizontally swinging doors in New York, New York, U.S.A.
Image provided by: Bo Dean
I know more!
Image 22
Pretty in pink - Toronto, Ontario, Canada
Image provided by: Peter Wilson
I know more!
Image 23
Buffalo, New York, U.S.A.
Image provided by: Caz Muni
I know more!
Image 24
Happy loading dock doors at the top landing of this "sidewalk" freight...
Warsaw, Poland
Image provided by: Pat Wayshak
I know more!
Image 25
A personalized freight elevator and landing entrance doors...
New York, New York, U.S.A.
Image provided by: Walter Lafayette
I know more!
Image 26
A look at the locking bars...
Image provided by: Ernie Peel
I know more!
Image 27
Looks brand new...
Image provided by: Stacie Peters
I know more!
Image 28
You can clearly see a slide-bolt/contact arrangement on
the right side in the larger image...for the burglar alarm?
Image provided by: Frank Larson
I know more!
Image 29
Restrictor bars in case the wire cloth is removed...
Image provided by: Walter Lafayette
I know more!
Image 30
One restrictor bar in case the glass/glazing is removed...
Image provided by: Walter Lafayette
I know more!
