Electric Elevators
Geared Traction Machines
Page 1
Return to elevatorbob's Electric Elevators
Return to elevatorbob's Elevator Pictures
Image 1
Montgomery geared machine
Image provided by: Neal Stubbs
I know more!
Image 2
Old geared machine
Image provided by: Neal Stubbs
I know more!
Image 3
Very old geared machine in a derelict building - notice the large flywheel on the end of the motor
Image provided by: Neal Stubbs
I know more!
Image 4
Rusty derelict geared machine
Image provided by: Roland Biggs
I know more!
Image 5
Same rusty derelict geared machine
Image provided by: Roland Biggs
I know more!
Image 6
Otis geared machine
Image provided by: Jason Summers
I know more!
Image 7
Otis geared machine circa 1926 in Brussels, Belgium
Image provided by: Rick Jensen
I know more!
Image 8
Otis geared machine
Image provided by: Rick Jensen
I know more!
Image 9
Westbrook geared machine
Image provided by: Rick Jensen
I know more!
Image 10
Schindler geared machine
Image provided by: Herbie T. Mann
I know more!
Image 11
Derelict geared machines in the recently (2006) demolished Donovan Building
home to Motown Records in Detroit, Michigan USA
Image provided by: Regent Isamoné
I know more!
Image 12
Geared machines
Image provided by: Regent Isamoné
I know more!
Jerry Follen informs me that: "The machines are from Hollister-Whitney."
Thank you Jerry!
Image 13
Geared machine
Image provided by: Rick Jensen
I know more!
Image 14
Geared machine
Image provided by: Rick Jensen
I know more!
Image 15
Geared machine
Image provided by: Herbie T. Mann
I know more!
Image 16
Paternoster driving machine
Image provided by: Herbie T. Mann
I know more!
Image 17
Geared machine at the Golden Gate Bridge (see the controller here)
Image provided by: Regent Isamoné
I know more!
Image 18
A very messy geared machine...very nice colors though!
Image provided by: Neal Stubbs
I know more!
Image 19
Image provided by: Hans van Lunsen - Holland
I know more!
Image 20
Image provided by: Hans van Lunsen - Holland
I know more!
Image 21
Image provided by: Hans van Lunsen - Holland
I know more!
Image 22
An MR 17 geared machine
Image provided by: Hans van Lunsen - Holland
I know more!
Image 23
A Titan belt driven geared traction machine (see the controller here and here)
Image provided by: Hans van Lunsen - Holland
I know more!
Image 24
An Otis geared traction machine and motor-generator set on the same bedplate
Image provided by: Hans van Lunsen - Holland
I know more!
Image 25
Two different geared machines arranged, as Hans' says, to be "like Siamese twins"
The left machine is a Havenmeier & Sanders - the right machine is a Kasper
Image provided by: Hans van Lunsen - Holland
I know more!
Image 26
The Havenmeier & Sanders machine (orange drive sheave)
Image provided by: Hans van Lunsen - Holland
I know more!
Image 27
The Kasper machine (blue drive sheave)
Image provided by: Hans van Lunsen - Holland
I know more!
Image 28
A Schindler machine with the UP and DOWN switch operated by the brake motor
Image provided by: Hans van Lunsen - Holland
I know more!
Image 29
An MR 17 geared machine waiting patiently to be installed by Hans
Image provided by: Hans van Lunsen - Holland
I know more!
Image 30
An Otis double motor and tandem geared machine
Image provided by: Hans van Lunsen - Holland
I know more!
